4125106S | LIY 1X0,14 GY | LAPP Single Core Cable
4125106S, Single Core Cable, PVC, stranded hook-up wire, Conductor Cross Section: 0.14mm², Core Colour: Grey, suited for occasional flexing
| Complete Electronics Part No. | 4125106S |
|---|---|
| Manufacturers Part No. | 4125106S |
| Control Cabinet Series | LiY |
| Number of Conductors: | 1 |
| Conductor Cross Section: | 0.14mm² |
| Rated Voltage: | 50V |
| Core Colour: | Grey |
Description
Fine-wire strand made of bare copper wires (IEC 60228 class 5)
Must not be connected to the mains supply voltage
Polyvinylchloride (PVC)-based core insulation
Approvals Based on VDE 0836
For fixed and protected installation
Packaging type: Spool
HAR Certified - No
LiY single core is a stranded hook-up wire
These cables are suited for occasional flexing
Conductor Cross Section: 0.14mm²
Core Colour: Grey
Cable Outer Diameter: 1.1mm
Flame-retardant according to IEC 60332-1-2
Temperature range, Fixed Install: : -30°C to +70°C
Operating voltage < 50 VAC
Oil-resistant - No
Halogen Free - No
UV-resistant - No
PWIS-free - Yes
Temperature range, Fixed Install: : -30°C to +70°C
Operating voltage < 50 VAC
Oil-resistant - No
Halogen Free - No
UV-resistant - No
PWIS-free - Yes
Fine-wire strand made of bare copper wires (IEC 60228 class 5)
Must not be connected to the mains supply voltage
Polyvinylchloride (PVC)-based core insulation
Approvals Based on VDE 0836
For fixed and protected installation
Packaging type: Spool
HAR Certified - No
Lapp Part Number: 4125106S
Cable Length: 500M
