Number of Conductors: 4

Conductor Diameter: 0.75mm²

Cable Outer Diameter: 9.5mm

With GN-YE Protective Conductor



Conductor material: Tin Plated Copper
Screen material: Tin plated copper braiding, coverage = 85% (nominal value)
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Thermoplastic elastomers (TPE)
Core identification: White numbers on black (EN 50334,  VDE 0293-1)
Inner Sheath material: Thermoplastic elastomers (TPE)
Inner sheath colour: Grey
Outer sheath material: Polyurethane (PUR)
Outer sheath colour: Grey (RAL 7001)



Nominal voltage: U0/U: 300/500 V AC rms according to IEC
Current rating according to VDE  0298-4
Test Voltage: 3kV
Temperature, fixed installation: -50°C to 90°C
Temperature, occasionally moved: -40°C to 90°C



Chemical resistant - Yes
Flame retardant - Yes  acc. to IEC 60332-1-2
Halogen Free - Yes
Hydrolysis resistant - Yes
Low-adhesion sheath surface - No
MUD resistant - Yes acc. to IEC 61892-4
Oil-resistant - Yes  acc. to EN 50363-10-2
Permanently immersible in water - Yes up to 10 metres @ 40°C
PWIS-free - Yes acc. to VDMA 24364-B2-L
Resistant to oil and drilling fluids
UV-resistant - Yes  acc. to EN ISO 4892-2, method A



For universal use for wiring machine-internal and cross-plant control circuits
Especially for environments where electromagnetic compatibility (EMC) is required.
Can be used in dry, wet and, especially, harsh and oily environments
The PUR outer sheath withstands high mechanical loads
The PUR outer sheath is resistant to mineral oil-based lubricants and highly resistant to chemicals



Outer sheath PUR material is resistant to abrasions, notches and cuts
Low-capacitance core insulation for long transmission paths
Flexible use at temperatures down to -40°C
Suitable for outdoor use, subject to the temperature range
Classified fire behaviour according to EU Directive 305/2011
CE marked, EAC certified, VDE certified



Reel Length= 100M

Lapp part number: 0012913
