DB Distribution Box

Split 360° cable entry system

For cables with and without connectors

  • With the new distribution box, centrally routed cables can be distributed 360° in all desired directions.
  • Cables (with and without connectors) with a diameter of 1 to 15 mm can be routed, sealed and strain relieved in accordance with EN 62444.
  • The distribution box is suitable for metric cut-outs M32 - M75* and can be fixed with a locknut, which is included in the delivery.
  • When using multi grommets, up to 48 cables can be routed and a high cable density is achieved.
  • Thanks to the screw mount cover and the use of split cable grommets, retrofits, repairs and maintenance can be done much more easily and quickly.
  • Can be combined with IMAS-CONNECT, KT and KT-DT Grommets
  • Hexagonal locknut included
*M75 available from spring 2023
