0026001 | ÖLFLEX HEAT 105 MC 2X0,75 | PVC Cable

PVC Power Cable, Number of Conductors: 2, Conductor Cross Section: 0.75mm², Nominal Voltage: U0/U: 300/500 V
More Information
Complete Electronics Part No 0026001
Manufacturers Part No. 0026001
Number of Conductors 2
Conductor Size 0.75mm²
Rated Voltage 300 / 500 V
Special Application Series OLFLEX HEAT 105 MC
Shielding Not Shielded
Protective Conductor No
Description

PVC Power Cable

Number of Conductors: 2

  • Conductor Cross Section: 0.75mm²
  • Nominal Voltage: U0/U: 300/500 V
  • Cable Outer Diameter: 6.2mm
  • Without Protective Conductor
  • Fine-wire strand made of bare copper wires
  • Cores twisted in layers
  • Core insulation: PVC
  • Outer sheath: PVC
  • Outer Sheath Colour: Black
  • Core ID: Colour Coded
  • Resistant to acids and alkalis
  • Flame Retardant
  • UV Resistant
  • Temperature Range: Short Term +105°C
  • Cable Length: 50Metres
