003002000400 | TouchBerry PI 10.1" Panel PC
New Version! Panel PC based on Raspberry PI 4 B board, pSLC 8Gb µSD Card + Linux, UPS + Raspberry PI 4 Model B
| Complete Electronics Part No. | 003002000400 |
|---|---|
| Manufacturers Part No. | 003002000400 |
Description
Touchberry PI Panel PC based on Raspberry PI 4 B board
- CPU Card: Quad-Core ARM Cortex-A72 1.5GHz
- USB: 2 x 2.0 (one of them is used for the touch screen), 2 x 3.0
- pSLC 8Gb µSD Card + Linux
- UPS
- 2GB RAM
- Wireless LAN / 2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
- Gigabit Ethernet – Serial TTL
- 12x GPIO, SPI, I2C, UART
- UPS Shield
- Raspberry PI 4 Model B - 2GB
- Additional Fan
- For industrial environment using Raspian or Ubuntu from Linux.
- Now with more EMC and ESD protection.
- More compact,
- Less weight and with anodized aluminum.
-
This Panel PC is based on GNU/Linux (Raspbian/Ubuntu) OS installed on an SD card. It has many interfaces built in: Ethernet, USB, WiFi...
- Using the Ethernet port or WiFi network you can remotely control all parameters, data and inputs/outputs of your control system.
- Furthermore, Touchberry PI comprises enough I/Os to replace PLCs on simple automation applications.
- Open protocols not only allow communication with other Industrial Shields PLCs, but also third-party devices and machinery.
