1249533 | ÖLFLEX HEAT 180 SIF A 1X50 BK | Single Core Cable
Fine wire silicone single core Cable,UL-AWM certified, Conductor Cross Section: 50mm², Core Colour: Black, Rated voltage: 1000 V AC rms according to UL AWM
| Complete Electronics Part No. | 1249533 |
|---|---|
| Manufacturers Part No. | 1249533 |
| Number of Conductors: | 1 |
| Conductor Cross Section: | 50mm² |
| Rated Voltage: | 600 / 1000V |
| Special Application Series: | OLFLEX HEAT 180 SiF A |
Description
Oil-resistant - Yes
Halogen Free - Yes (according to IEC 60754-1)
UV-resistant - No
PWIS-free - No
For use in environments with high operating temperatures
Core insulation base material: Silicone
Suitable for fixed and occasionally moved Installations
Fine wire silicone single core Cable
UL AWM - recognised, 1000 V AC rms
Conductor Cross Section: 50mm²
Conductor Outer Diameter: 13.5mm
Core Colour: Black
Conductor: Tin Plated Copper, IEC 60228 class 5: fine-wire
Flame retardance according to IEC 60332-1-2, UL FT2
Temperature range, Fixed Install: -50°C to +180°C
Temperature, occasionally moved: -50°C to +180°C
Rated voltage: U0/U: 0,6/1 kV AC rms according to IEC
UL rated Voltage: 1000 V AC rms according to UL AWM
Test Voltage 3 kV
Temperature range, Fixed Install: -50°C to +180°C
Temperature, occasionally moved: -50°C to +180°C
Rated voltage: U0/U: 0,6/1 kV AC rms according to IEC
UL rated Voltage: 1000 V AC rms according to UL AWM
Test Voltage 3 kV
Oil-resistant - Yes
Halogen Free - Yes (according to IEC 60754-1)
UV-resistant - No
PWIS-free - No
For use in environments with high operating temperatures
Core insulation base material: Silicone
Suitable for fixed and occasionally moved Installations
Cable Length: 100M
Lapp Part Number: 1249533
