Conductor material: Bare Copper
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Polyvinylchloride (PVC)
Core identification: White numbers on black (EN 50334)
Outer sheath material: Polyurethane (PUR)
Outer sheath colour: Black (RAL 9005)



Nominal voltage: U0/U: 300/500 V AC rms according to IEC
Operating voltage of 1000 V according to UL
Current rating according to VDE  0298-4
Test Voltage: 4kV
Temperature, fixed installation: -40°C to 80°C
Temperature, occasionally moved: -5°C to 80°C



Chemical resistant - Yes
Flame retardant - Yes  acc. to IEC 60332-1-2
Halogen Free - No
Hydrolysis resistant - Yes
Low-adhesion sheath surface - No
Oil-resistant - Yes  acc. to EN 50363-10-2

Ozone resistant - Yes
PWIS-free - Yes acc. to VDMA 24364-B2-L
UV-resistant - Yes  acc. to EN ISO 4892-2, method A
Water resistant - Yes
Weather resistant - Yes



For universal use for wiring machine-internal and cross-plant control circuits
Can be used in dry, wet and, especially, harsh and oily environments
The PUR outer sheath withstands high mechanical loads
The PUR outer sheath is resistant to mineral oil-based lubricants and highly resistant to chemicals
Outer sheath PUR material is resistant to abrasions, notches and cuts



Inner interstice filling of the outer sheath made of PVC
Suitable for outdoor use, subject to the temperature range
For fixed installation and occasional flexing without tensile strain
CE marked, EAC certified, UL recognised, cUR recognised
