Number of Conductors: 3

Conductor Diameter: 0.75mm²

Cable Outer Diameter: 7.9mm

Without Protective Conductor

EMC compliant copper screening



Conductor material: Bare Copper
Conductor design: IEC 60228 class 5:-fine wire
Screen: Tin-plated copper braiding, coverage = 85% (nominal value)
Core insulation: Polyvinylchloride (PVC P8/1, better than the PVC compound TI2)
Core identification: White numbers on black (acc. to EN 50334)
Inner Sheath material: PVC compound TM2 acc. to EN 50363-4-1
Inner Sheath Colour: Grey
Outer sheath material: Polyurethane (PUR)
Outer sheath colour: Grey (RAL 7001)



Nominal voltage: U0/U: 300/500 V AC rms according to IEC
Current rating according to VDE  0298-4
Test Voltage: 4kV
Temperature, fixed installation: -40°C to 80°C
Temperature, occasionally moved: -5°C to 70°C



Chemical resistant - Yes
Flame retardant - No
Halogen Free - No
Hydrolysis resistant - Yes
Low-adhesion sheath surface - No
Oil-resistant - Yes  acc. to EN 50363-10-2
PWIS-free - Yes acc. to VDMA 24364-B2-L
UV-resistant - Yes  acc. to EN ISO 4892-2, method A
Water resistant - Yes
Weather resistant - Yes



For universal use for wiring machine-internal and cross-plant control circuits
Can be used in dry, damp and, especially, harsh and oily environments
The PUR outer sheath withstands high mechanical loads
PUR outer sheath is highly chemical resistant and highly oil resistant
Outer sheath PUR material is resistant to abrasions, notches and cuts



Especially for environments where electromagnetic compatibility (EMC) is required.
Ideal protection against electromagnetic interference thanks to copper screening braiding
Suitable for outdoor use, subject to the temperature range
For fixed installation and occasional flexing without tensile strain
CE marked, EAC certified, Ecolab certified



Reel Length= 100M

Lapp part number: 1313853
