Meets EN 50264-3-1 type M and EN 45545-2

Number of Conductors: 1

Conductor Cross Section: 70.0mm²

Cable Outer Diameter: 13.6mm

Tinned-copper strand, fine-wire - IEC 60228 class 5

Insulation: Electron beam cross-linked Polymer compound

Colour: Black



Flame-retardant acc. to EN 60332-1-2

Low smoke density acc. to EN 61034-2

Halogen-free acc. to EN 60754-1

Oil resistant acc. to EN 50264-3-1

Fuel resistant acc. to EN 50264-3-1

Acid resistant acc. to EN 50264-3-1

Alkali resistant acc. to EN 50264-3-1

Ozone resistant acc. to EN 50264-3-1/EN 50305

UV-resistant according to EN 50525-1 (cables with a black sheath are suitable for permanent outdoor use)



Nominal Voltage: AC 0.6/1 kV rms according to IEC

Current rating according to EN 50355



Temperature Range (Fixed Install): -45°C to 120°C

Temperature, occasional flexing: -35°C to 90°C



Cable Length: 100M

Lapp part number: 15331010



For use in railway vehicles
Halogen free and highly flame retardant
M = extra low temperature, extra oil and fuel resistant
For fixed installations and applications where limited movement may occur
Can be used in dry, damp and, especially, harsh and oily environments
Good chemical resistance
Extended temperature range
