15340013 | OLFLEX TRAIN 340 600V 3X10 | Rolling Stock Cable
Multi Core Control Cable For Railway Applications, Meets EN 50264-3-2 type MM and EN 45545-2, Number of Conductors: 3, Conductor Cross Section: 10.0mm²
| Complete Electronics Part No. | 15340013 |
|---|---|
| Manufacturers Part No. | 15340013 |
| Number of Conductors: | 3 |
| Conductor Cross Section: | 10.0mm² |
| Rated Voltage: | 600V |
| Special Application Series: | OLFLEX TRAIN 340 |
| Shielding: | Not Shielded |
| Cable Length: | 100 Metres |
Description
15340013 | OLFLEX TRAIN 340 600V 3X10
Type MM Multi Core Control Cable For Railway Applications
Meets EN 50264-3-2 type MM and EN 45545-2
Number of Conductors: 3
Conductor Cross Section: 10.0mm²
Cable Outer Diameter: 14.0mm
Without protective conductor
Tinned-copper strand, fine-wire - IEC 60228 class 5
Colour of core insulation: Black with white numbers
Core colour code: EN 50334, VDE 0293-1
Core insulation: Electron beam cross-linked polymer compound EI 109
Outer Sheath: Electron beam cross-linked polymer compound EM 104
Core insulation: Electron beam cross-linked polymer compound EI 109
Outer Sheath: Electron beam cross-linked polymer compound EM 104
Outer sheath colour: Black
Halogen-free acc. to EN 60754-1
Flame-retardant acc. to EN 60332-1-2
Cold-resistant
Acid and Alkali resistant to EN 50264-3-2
Fuel resistant acc. to EN 50264-3-2
Oil resistant acc. to EN 50264-3-2
Ozone resistant acc. to EN 50264-3-2/ EN 50305
Nominal Voltage: AC 0.6/1 kV rms according to IEC
Current rating according to EN 50355
Temperature Range (Fixed Install): -45°C to 120°C
Temperature, occasional flexing: -35°C to 90°C
Cable Length: 100M
Lapp part number: 15340013
