15345012 | OLFLEX TRAIN 345 C 600V 2X10 | Rolling Stock Cable
Screened Multi Core Control Cable For Railway Applications, Meets EN 50264-3-2 type MM S and EN 45545-2, Conductors: 2, Conductor Cross Section: 10.0mm²
| Complete Electronics Part No. | 15345012 |
|---|---|
| Manufacturers Part No. | 15345012 |
| Number of Conductors: | 2 |
| Conductor Cross Section: | 10.0mm² |
| Rated Voltage: | 600V |
| Special Application Series: | OLFLEX TRAIN 345 C |
| Shielding: | Shielded / Screened |
| Cable Length: | 100 Metres |
Description
15345012 | OLFLEX TRAIN 345 C 600V 2X10
Type MM S Multi Core Control Cable - Screened
Meets EN 50264-3-2 type MM S and EN 45545-2
Number of Conductors: 2
Conductor Cross Section: 10.0mm²
Cable Outer Diameter: 14.2mm
Without protective conductor
Tinned-copper strand, fine-wire - IEC 60228 class 5
Wrapping: Halogen-free plastic foil
Screen: Tinned-copper braiding
Colour of core insulation: Black with white numbers
Core colour code: EN 50044, VDE 0293-1
Core insulation: Electron beam cross-linked polymer compound EI 109
Outer Sheath: Electron beam cross-linked polymer compound EM 104
Core insulation: Electron beam cross-linked polymer compound EI 109
Outer Sheath: Electron beam cross-linked polymer compound EM 104
Outer sheath colour: Black, similar to RAL 9005
Oil and Fuel Resistant
Acid and Alkali Resistant
Ozone and Cold resistant
Zero halogen according to IEC 60754-1, EN 60684-2
UV-resistant according to EN 50525-1 (cables with a black sheath are suitable for permanent outdoor use)
UV-resistant according to EN 50525-1 (cables with a black sheath are suitable for permanent outdoor use)
Nominal Voltage: AC 0.6/1 kV AC rms according to IEC
Current rating according to EN 50355
Temperature Range (Fixed Install): -45°C to 120°C
Temperature, occasional flexing: -35°C to 90°C
Cable Length: 100M
Lapp part number: 15345012
