Meets EN 50264-3-2 type MM and EN 45545-2

Number of Conductors: 32

Conductor Cross Section: 1.0mm²

Cable Outer Diameter: 15.9mm

Tinned-copper strand, fine-wire - IEC 60228 class 5



Colour of core insulation: Black with white numbers

Core colour code: EN 50334, VDE 0293-1
Core insulation: Electron beam cross-linked polymer compound EI 109
Outer Sheath  insulation: Electron beam cross-linked polymer compound EM 104

Outer sheath colour: Black



Oil and Fuel Resistant

Acid and Alkali Resistant

Ozone and Cold resistant

Halogen-free acc. to EN 60754-1

Flame-retardant acc. to EN 60332-1-2

Low smoke density acc. to EN 61034-2

UV-resistant according to EN 50525-1 (cables with a black sheath are suitable for permanent outdoor use)



Nominal Voltage: 300/500 V AC rms according to IEC

Current rating according to EN 50355



Temperature Range (Fixed Install): -45°C to 120°C

Temperature, occasional flexing: -35°C to 90°C



Cable Length: 100M

Lapp part number: 15350007



For use in railway vehicles
For fixed installations and applications where limited movement may occur
Resistant to mechanical influences in harsh environmental conditions
Good chemical resistance
Extended temperature range
Reduced flame spreading
