1600119 | H07RN-F 3G4 | Harsh Conditions Cable
Rubber power and control cable, Heavy standard construction, Number of Conductors: 3, Conductor Diameter: 4.0mm², With GN/YE Protective conductor
| Complete Electronics Part No. | 1600119 |
|---|---|
| Manufacturers Part No. | 1600119 |
| Series: | H07RN F |
| Number of Conductors: | 3 |
| Conductor Cross Section: | 4.0mm² |
| Rated Voltage: | 450 / 750 V |
| Cable Type: | Rubber power and control cable |
| Shielding: | Not Shielded |
| Protective Conductor: | Yes |
| Cable Jacket: | Rubber compound, type EM2 |
| Cable Length: | 50 Metres |
Description
1600119 | H07RN-F Cable, 3G4
Rubber Power and Control Cable
Number of Conductors: 3
Conductor Diameter: 4.0mm²
Cable Outer Diameter: 12.7 - 14.4mm
With GN-YE Protective Conductor
Conductor material: Bare Copper
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Rubber (E14)
Core identification: Colour-coded acc. to VDE 0293-308 / Black cores with white numbers
Outer Sheath material: Rubber (EM2 acc. to EN 50363-2-1)
Outer Sheath colour: Black
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Rubber (E14)
Core identification: Colour-coded acc. to VDE 0293-308 / Black cores with white numbers
Outer Sheath material: Rubber (EM2 acc. to EN 50363-2-1)
Outer Sheath colour: Black
Nominal voltage: U0/U: 450/750 V AC rms according to IEC
Current rating according to VDE 0298-4
Test Voltage: 2.5kV
Temperature, fixed installation: -40°C to 60°C
Temperature, occasionally moved: -25°C to 60°C
Current rating according to VDE 0298-4
Test Voltage: 2.5kV
Temperature, fixed installation: -40°C to 60°C
Temperature, occasionally moved: -25°C to 60°C
Flame retardant - Yes acc. to IEC 60332-1-2
Halogen Free - No
Low-adhesion sheath surface -No
Oil-resistant - Yes (EN 50363-2-1)
Permanently immersible in water - No
PWIS-free - Yes
UV-resistant - Yes, (cables with a black sheath are suitable for permanent outdoor use)
Halogen Free - No
Low-adhesion sheath surface -No
Oil-resistant - Yes (EN 50363-2-1)
Permanently immersible in water - No
PWIS-free - Yes
UV-resistant - Yes, (cables with a black sheath are suitable for permanent outdoor use)
For use with hand-held or power supply devices as well as commercial and agricultural machine tools.
For fixed installation and occasional flexing
Withstands heavy mechanical stress
Can be used in dry, wet and especially in harsh and oily environments
Suitable for outdoor use, subject to the temperature range
For fixed installation and occasional flexing
Withstands heavy mechanical stress
Can be used in dry, wet and especially in harsh and oily environments
Suitable for outdoor use, subject to the temperature range
Flexible use at temperatures down to -25°C
Made according to harmonised European type H07RN-F with ◁HAR▷ testing mark or HAR-identification thread
◁HAR▷-style cables are widely accepted and can be used in Europe
CE Marked, EAC Certified, ◁HAR▷ Certified
Made according to harmonised European type H07RN-F with ◁HAR▷ testing mark or HAR-identification thread
◁HAR▷-style cables are widely accepted and can be used in Europe
CE Marked, EAC Certified, ◁HAR▷ Certified
Reel Length= 50M
Lapp part number: 1600119
