1600250 | H05RN-F 2X0,75 | Harsh Conditions Cable
Rubber cable for handheld devices, Number of Conductors: 2, Conductor Diameter: 0.75mm², Cable Outer Diameter: 5.7 - 7.4mm, Without GN/YE Protective conductor
| Complete Electronics Part No. | 1600250 |
|---|---|
| Manufacturers Part No. | 1600250 |
| Series: | H05RN F |
| Number of Conductors: | 2 |
| Conductor Cross Section: | 0.8mm² |
| Rated Voltage: | 300 / 500 V |
| Cable Type: | Rubber cable for handheld devices |
| Shielding: | Not Shielded |
| Protective Conductor: | No |
| Cable Jacket: | Rubber compound, type EI 4 |
| Cable Length: | 100 Metres |
Description
1600250 | H05RN-F Cable, 2X0.75
Multi Core Rubber Power and Control Cable
Number of Conductors: 2
Conductor Diameter: 0.75mm²
Cable Outer Diameter: 5.7 - 7.4mm
Without Protective Conductor
Conductor material: Bare Copper
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Rubber (E14)
Core identification: Colour-coded acc. to VDE 0293-308 / Black cores with white numbers
Outer Sheath material: Rubber (EM2 acc. to EN 50363-2-1)
Outer Sheath colour: Black
Conductor design: IEC 60228 class 5:-fine wire
Core insulation: Rubber (E14)
Core identification: Colour-coded acc. to VDE 0293-308 / Black cores with white numbers
Outer Sheath material: Rubber (EM2 acc. to EN 50363-2-1)
Outer Sheath colour: Black
Nominal voltage: U0/U: 300/500 V AC rms according to IEC
Current rating according to VDE 0298-4
Test Voltage: 2kV
Max. conductor resistance at 20°C: 19.5 Ω/km
Temperature, fixed installation: -40°C to 60°C
Temperature, occasionally moved: -25°C to 60°C
Current rating according to VDE 0298-4
Test Voltage: 2kV
Max. conductor resistance at 20°C: 19.5 Ω/km
Temperature, fixed installation: -40°C to 60°C
Temperature, occasionally moved: -25°C to 60°C
Flame retardant - Yes acc. to IEC 60332-1-2
Halogen Free - No
Low-adhesion sheath surface -No
Oil-resistant - Yes (EN 50363-2-1)
Permanently immersible in water - No
PWIS-free - No
UV-resistant - Yes, (cables with a black sheath are suitable for permanent outdoor use)
Halogen Free - No
Low-adhesion sheath surface -No
Oil-resistant - Yes (EN 50363-2-1)
Permanently immersible in water - No
PWIS-free - No
UV-resistant - Yes, (cables with a black sheath are suitable for permanent outdoor use)
Typical areas of application are also strings of lights and hand-held inspection lamps
For fixed installation and occasional flexing
Withstands light mechanical stress
Can be used in dry, wet and especially in harsh and oily environments
Suitable for outdoor use, subject to the temperature range
For fixed installation and occasional flexing
Withstands light mechanical stress
Can be used in dry, wet and especially in harsh and oily environments
Suitable for outdoor use, subject to the temperature range
Flexible use at temperatures down to -25°C
Not suitable for torsional load
Made according to harmonised European type H05RN-F with ◁HAR▷ testing mark or HAR-identification thread
◁HAR▷-style cables are widely accepted and can be used in Europe
CE Marked, EAC Certified, ◁HAR▷ Certified
Not suitable for torsional load
Made according to harmonised European type H05RN-F with ◁HAR▷ testing mark or HAR-identification thread
◁HAR▷-style cables are widely accepted and can be used in Europe
CE Marked, EAC Certified, ◁HAR▷ Certified
Reel Length= 100M
Lapp part number: 1600250
