1605520 | SF-5EP1N8AWA00 | Device Connector
Device connector, front mounting, straight, Screw locking, M23, Number of positions: 5+PE, Type of contact: Male
| Complete Electronics Part No. | 1605520 |
|---|---|
| Manufacturers Part No. | 1605520 |
| Type: | Device Connector |
| Male/Female: | Male |
| Number of poles | 5+PE |
| Shielding: | Shielded / Screened |
Description
1605520 / SF-5EP1N8AWA00
Device connector, front mounting
- Straight
- Screw locking
- M23
- Number of positions: 5+PE
- Type of contact: Male
- Crimp connection
- Axial O-ring
- 4xØ3,2
- Shielded: Yes
- Flange dimensions: 26 mm x 26 mm, Cable diameter: 0 mm...0 mm
