20122| RSTS 8X-S478/1 M | Network Cable
Gigabit Ethernet Cat7 Data Single-Ended Cordset: M12 Standard, male, straight, 8-pin, X-coded, shielded, black body, Cable Length: 1 metre
| Complete Electronics Part No. | 20122 |
|---|---|
| Manufacturers Part No. | 20122 |
| Category | CAT 7 |
| Cable Jacket: | TPE |
Description
RSTS 8X-S478/1 M
Gigabit Cat 7 Cordset, Single ended
- Single-Ended Cordset:
- M12 Standard, male,straight, 8-pin, X-coded
- Shielded
- 8-wires, 4x2x 0.14 mm²
- Operating Voltages: 50 V AC / 60 V DC, 0.5 A
- Outer sheath colour Blue
- Cable Jacket material: TPE
- Operating Temperature: - 40 °C - + 80°C
- Ingress Protection: IP65, IP67
- Flammability Class (Molded Body): UL 94 V-0
- Spark weld resistant
- Part Number: 20122
- Cable Length: 1 M (other lengths avaiable, see below table)
