2170465 | ETHERLINE CAT. 6A P | Network Cable

Ethernet cable Category 6A, Class EA for fixed installation - verified up to 500 MHz, Halogen Free
More Information
Complete Electronics Part No. 2170465
Manufacturers Part No. 2170465
Category CAT 6A
Cable Jacket: PUR
Description

ETHERLINE CAT. 6A P

Ethernet cable for Category 6A / class EA

  • Verified up to 500 MHz
  • For PROFINET applications with 4 pairs
  • PUR outer sheath, Halogen Free
  • High-quality, double screening
  • Peak operating voltage: (not for power applications) 125 V
  • Characteristic impedance: 100 ohm at 1 - 100 MHz
  • Solid bare copper wire AWG22
  • Core insulation made of polyethylene (PE)
  • Colour: green (based on RAL 6018)
  • 4pair: 100Mbit/s up to 10 Gbit/s for Industrial Ethernet
  • For Use in harsh industrial environments
  • Can be used in dry or damp rooms
  • Core Diameter: 1.5mm
  • Cable Outer Diameter 8.7mm
  • Reel Length: 100Metres
