27600108 | HITRONIC HQN1500 8G 62,5/125 OM1 | Optical Fibre Cable
Multimode Fibre Optic outdoor cable, Cable Type: Multimode 62.5 /125 OM 1, Number of fibres: 8, Cable Outer Diameter: 7.3mm, Colour-coded fibres
| Complete Electronics Part No. | 27600108 |
|---|---|
| Manufacturers Part No. | 27600108 |
| Series: | Hitronic HQN Cable |
| Number of Conductors: | 8 |
| Cable Jacket: | PE |
| Optical Cable Type: | Multimode 62.5 / 125 |
Description
27600108 HITRONIC® HQN 1500 8 G 62.5/125 OM1
HITRONIC® HQN Optical Outdoor Cable
Product Design
Wavelength information: for 850 nm applies 3.5 dB / km as well as 200 MHz*km
Wavelength information: for 1300 nm applies 1.5 dB / km as well as 500 MHz*km
Classification: Gel-filled loose tube cable
Number of cores: 1
Number of fibres per core: 8
Number of fibres: 8
Strain relief due to: Glass yarns
Fibre type: Multi-mode fibre
Max. conductor temperature, fixed installation: -40°C to 70°C
Max. conductor temperature, occasionally moved: -5°C to 50°C
Electrical / Insulation Parameters
Nominal outer diameter: 7.3 mm
Diameter fibre core: 62.5 µm
Diameter fibre cladding: 125 µm
Diameter of primary coating: 245 µm
With tight buffer: No
Ripcord below outer sheath: Yes
Basic material of outer sheath: Polyethylene (PE)
Outer Sheath colour: Black (RAL9005)
Armouring type: None
Core identification: Colours
Weight: 40 kg/km
Product Features
Flame retardant - No
For continuous flexing:- No / Occasional
For torsional load: No
For continuous flexing:- No / Occasional
For torsional load: No
Windable - No
Halogen Free - Yes acc. to IEC 60754-1
Suitable for EX-applications - No
Oil Resistant - No
UV Resistant - Yes
Weather Resistant - Yes
PWIS-free - No
Tensile force, Fixed installation: 1500 N
Tensile force, short term: 3000N
With rodent protection - Yes
With armouring - No
General Information
Laterally watertight
Longitudinally watertight
Can be used in dry, damp, wet and harsh environments
Suitable for installation underground either direct or in protective cable conduit
The PE outer sheath is highly resistant to acids and alkaline solutions
Suitable for indoor and outdoor use
Not suitable for EX-applications
Suitable for medium mechanical stress
Product standard according to IEC 60794
Lapp part number: 27600108
Length: 100M
