42208 | KEL 24/12-E black | icotek Cable Entry Frame
KEL 24-E Cable Entry Frame, With an additional middle frame ,Number of Grommets: 11 Small + 1 Large, Cut-Out Dimension: 112 x 66mm
| Complete Electronics Part No. | 42208 |
|---|---|
| Manufacturers Part No. | 42208 |
| Number of Cables: | max 45 |
| ATEX Approval: | Not ATEX Approved |
| Series: | KEL 24 |
Description
KEL 24-E Cable Entry Frame
With an additional middle frame
Number of Grommets: 11 Small + 1 Large
Flat Rubber Gasket included
Material: Polyamide (PA)
Flame Class: UL94-V0, self-extinguishing
IP Rating: IP54 with Gasket
Temperature Rating: - 40°C to +140°C
Length: 147mm
Width: 83
Height: 17mm
Cut out size: 112 x 66mm
Max No. cables: 45
Max Cable Diameter 35mm
Width: 83
Height: 17mm
Cut out size: 112 x 66mm
Max No. cables: 45
Max Cable Diameter 35mm
Halogen-free and silicone-free
Mounting Screws: Mild steel, galvanically zinc plated
Snap-in with KEL-SNAP
Packing Unit: 1
Icotek Order Number: 42208
EAN: 4251269307997
