50583 | KEL-DP-E 86/17 Black | Cable Entry Plate
KEL-DP Cable Entry Plate, For routing cables without connectors, Cut out Dimensions: 85 x 18mm, clamping range 10 x 1 to 6.5mm +1 x1 to 12.1mm
| Complete Electronics Part No. | 50583 |
|---|---|
| Manufacturers Part No. | 50583 |
| Number of Cables: | max 17 |
| Core Colour: | Black |
| ATEX Approval: | Not ATEX Approved |
Description
Max no. of cables: 17
Max Cable Diameter 12.1mm
Clamping range:- 16 x 1 to 6.5mm + 1 x 1 to 12.1mm
Material: Elastomer
Flame Class: UL94-V0, self-extinguishing
Temperature Rating: -30°C to +100°C
Silicone free, Halogen free
Ingress Protection: IP54/IP64
ST-B Plugs can be used for sealing pierced membranes if cables have been removed
Minimum wall thickness 1.5mm
Maximum wall thickness 2.5mm
Packing Unit: 10
Icotek Part Number: 50583
EAN: 4251269314995
KEL-DP-E 86/17 bk Cable Entry Plate
For routing cables without connectors
Colour: Black
Length: 102mm
Width: 25mm
Height: 12mm
Mounting height:5mm
Mounting: Snap in
Length: 102mm
Width: 25mm
Height: 12mm
Mounting height:5mm
Mounting: Snap in
Max no. of cables: 17
Max Cable Diameter 12.1mm
Clamping range:- 16 x 1 to 6.5mm + 1 x 1 to 12.1mm
Material: Elastomer
Flame Class: UL94-V0, self-extinguishing
Temperature Rating: -30°C to +100°C
Silicone free, Halogen free
Ingress Protection: IP54/IP64
ST-B Plugs can be used for sealing pierced membranes if cables have been removed
Minimum wall thickness 1.5mm
Maximum wall thickness 2.5mm
Packing Unit: 10
Icotek Part Number: 50583
EAN: 4251269314995
