942133012 | OCTOPUS 4GE-16FE-PoE-HV-Trainrouter
OCTOPUS IP67/IP65 Industrial Ethernet Switch, 20 ports in total
| Complete Electronics Part No. | 942133012 |
|---|---|
| Manufacturers Part No. | 942133012 |
| Number Of PoE Ports: | 15 |
| Total Ethernet Ports: | 20 |
| Operating Voltage: | DC 72V - 110V |
| Mounting: | Wall |
| IP Rating: | IP65 / 67 |
Description
OCTOPUS Managed Ethernet Switch
IP65 / IP67 switch
In accordance with IEEE 802.3
Store-and-forward-switching
HiOS Layer 3 Standard
TP-cable
20 ports in total
Uplink ports 10/100/1000BASE-TX
M12 "X"-coded, 8-pins
Local ports 10/100BASE-TX M12 "D"-coded, 4-pin
15 x PoE(+) Ports (phantom power)
V.24 interface 1 x M12 4-pin socket, A coding
USB interface 1 x M12 5-pin socket, A coding
Operating Voltage 1 x 72/110 VDC (50.4 .. 138 VDC)
Operating temperature -40-+70 °C
Dimensions (WxHxD) 261 mm x 186 mm x 95 mm
Weight 3.5 kg
Mounting Wall mounting
Part Number: 942133012
