942170043 | BRS40 8TX/4SFP-EEC-HL | BOBCAT Ethernet Switch
Managed 12 port Fast-Ethernet-Switch, 8x 10/100/1000BASE TX / RJ45, 4x 100/1000Mbit/s fiber, Operating Temperature -40-+70 °C
| Complete Electronics Part No. | 9421070043 |
|---|---|
| Manufacturers Part No. | 9421070043 |
| Ethernet Product Type: | BRS40 |
| Total 10/100 (RJ45) Ports | 8 |
| Total 100/1000 (FX) Ports | 4 |
| Total Ethernet Ports | 12 |
| Operating Voltage: | DC 12V / 24V |
| Mounting: | DIN Rail |
| IP Rating: | IP30 |
Description
BRS40-0012OOOO-TTCX99HHSES
12 port Fast-Ethernet-Switch
- Managed
- Mounting: DIN rail
- Fanless design
- Uplink: 2 x SFP Slot (100/1000 Mbit/s)
- Uplink: 2 x SFP Slot (100/1000 Mbit/s)
- 8x 10/100/1000BASE TX / RJ45
- Operating voltage 2 x 12 to 24 VDC
- Operating temperature 0 ºC ... 60 ºC
- Weight: 570g
- Protection Class: IP30
- Housing Material: Plastic
- Accessories available to order:-
- AutoConfiguration Adapter ACA22-USB-C (EEC) 942-239-001
- 6-pin terminal block with screw lock (50 pieces) 943 845-013
- 2-pin terminal block with screwlock (50 pieces) 943 845-009
- Industrial HiVision Network Management Software 943 156-xxx
