942170043 | BRS40 8TX/4SFP-EEC-HL | BOBCAT Ethernet Switch
Managed 12 port Fast-Ethernet-Switch, 8x 10/100/1000BASE TX / RJ45, 4x 100/1000Mbit/s fiber, Operating Temperature -40-+70 °C
| Complete Electronics Part No. | 9421070043 |
|---|---|
| Manufacturers Part No. | 9421070043 |
| Ethernet Product Type: | BRS40 |
| Total 10/100 (RJ45) Ports: | 8 |
| Total 100/1000 (FX) Ports: | 4 |
| Total Ethernet Ports: | 12 |
| Operating Voltage: | DC 12V / 24V |
| Mounting: | DIN Rail |
| IP Rating: | IP30 |
Description
BRS40-0012OOOO-TTCX99HHSES
12 port managed Fast-Ethernet-Switch
Uplink: 2 x SFP Slot (100/1000 Mbit/s)
Uplink: 2 x SFP Slot (100/1000 Mbit/s)
8x 10/100/1000BASE TX / RJ45
Operating voltage 2 x 12 to 24 VDC
Operating temperature 0 ºC ... 60 ºC
Mounting: DIN rail
Fanless design
Weight: 570g
Protection Class: IP30
Housing Material: Plastic
Accessories available to order:-
AutoConfiguration Adapter ACA22-USB-C (EEC) 942-239-001
6-pin terminal block with screw lock (50 pieces) 943 845-013
2-pin terminal block with screwlock (50 pieces) 943 845-009
Industrial HiVision Network Management Software 943 156-xxx
