99402 | EMC-KEL-DS 16\8 | Split EMC cable entry frames
EMC-KEL-DS 24|4 | Split EMC cable entry frames, Max number of cables 4, Max cable diameter 35mm
| Complete Electronics Part No. | 99402 |
|---|---|
| Manufacturers Part No. | 99402 |
Description
Split EMC Cable Entry Frame
- For shielding cables with connectors
- Max number of cables: 8
- Max cable diameter: 17mm
- Length: 1120mm
- Width: 58mm
- Height: 17mm
- Mounting height: 17mm
- Cut out size: 112 x 36mm
- No of screw holes: 4
- Diameter of screw holes: 5.8mm
- Screw material: Mild steel, galvanicall zinc plated
- Suitable for grommits: 8 x EMC-KT small
- Material: Polyamide, highly conductive coating
- Flame class: UL94-V0, self-extinguishing
- Operating temperature:-40C° to 140C°
- Mounting options: Screw type mounting
- Vibration Proof
- Part Number: 99402
- EAN: 4251269319389
- PU: 1
