99434 | EMC-KVT-DS 63\1 with plastic locknut

EMC-KVT-DS 63\1 with plastic locknut, Max cable diameter 35mm, Max number of cables 1
More Information
Complete Electronics Part No. 99434
Manufacturers Part No. 99434
Description

 Split EMC Cable Gland

  • Max number of cables: 1
  • Max cable diameter: 35mm
  • Mounting height: 23mm
  • Cut out size, metric: M63
  • Cut out size, round: 63.4mm
  • Thread: M63 x 1.5
  • Thread Length: 14mm
  • Suitable for grommits: 1 x KT large or 1 x EMC-KT large
  • Locknut: Plastic (highly conductive coating)
  • Flame class: UL94-V0, self-extinguishing
  • Operating temperature:-40 C° to 90 C°
  • Mounting options: Fasten with locknut
  • Part Number: 99434
  • EAN: 4251269322587
  • PU: 1
