BZV05/Z0000/08 | BZV05Z000008 | Polysnap IEC Inlet
Polysnap Non-Fused IEC Power Inlet with single pole green neon switch, Vertical, Panel Mount
| Complete Electronics Part No. | BZV05Z000008 |
|---|---|
| Manufacturers Part No. | BZV05/Z0000/08 |
| Type: | Panel Mount Connector |
| IEC Type | IEC Inlet |
| IEC Class | Sheet C16 Class 1 |
| Number of Inlets / Outlets | 1 |
| Mounting: | Snap Fit Fixing |
| Module Arrangement | Vertical |
| Number of poles | 3 |
| Male/Female: | Male |
| Switch Type | Single Pole with Green Neon |
| Fuse Size: | Non Fused |
| Termination: | 6.3mm Spade Terminals |
| Rated Voltage: | 250V |
| Rated Current: | 10 Amps |
Description
BZV05Z000008
Polysnap Non-Fused IEC Power Inlet
- Non-Fused
- single pole green neon switch
- 6.3mm Tab
- Vertical
- Snap To Panel Panel Mount
- Rated Current: 10A
- Rated Voltage: 250V ac
- Class C16
