BZV47/Z0000/74 | BZV47Z000074 | Bulgin IEC
Polysnap - Sheet F IEC Vertical Outlet Shuttered with a SP Green Neon Switch (I/O)
| Complete Electronics Part No. | BZV47Z000074 |
|---|---|
| Manufacturers Part No. | BZV47/Z0000/74 |
| Type: | Panel Mount Connector |
| IEC Type | IEC Outlet - Shuttered |
| IEC Class | Sheet F Class I |
| Mounting: | Snap Fit Fixing |
| Module Arrangement | Vertical |
| Number of poles | 3 |
| Male/Female: | Female |
| Switch Type: | Single Pole with Green Neon |
| Termination: | 6.3mm Spade Terminals |
| Rated Voltage: | 250V |
| Rated Current: | 10 Amps |
Description
BZV47/Z0000/74
Polysnap - Sheet F IEC Vertical Outlet
- Shuttered With a SP Green Neon Switch (I/O)
- Panel Mount
- Snap in
- 6.3mm Tags (outlet)
- 10Amp
- 250Vac
- -40°C/+70°C
