Polysnap IEC Connectors

Bulgin Polysnap IEC Connectors

  • Bulgins popular range of polysnap mains power inlet modules deliver a highly versatile and flexible solution to panel design.
  • Polysnap allows for  combinations of mains inlets and outlets, filtered inlets, switches, fuseholders, voltage selectors and indicators mounted in a choice of horizontal or vertical format bezels ready for quick snap-fit assembly.
  • The compact design sits in the minimum of panel area where space is at a premium and has a single rectangular mounting hole  allowing for easy installation for the mains power entry module.
  • To harmonize with Bulgin’s range of polysnap modules the polyflange range offers a flange fixing alternative for applications that suit the reliability of screw fixing.

Styles include the following:

  • C14, C14 FUSED INLETS, C16 FUSED INLETS, C20, OUTLETS SHEET F, C14 INLET/OUTLET, C14 FUSED Combinations with bezel options to include Snap to panel vertical, Snap to panel horizontal and flange mount vertical.
  • There are  neon switch variations and quick-connect contact terminations.
Read More

Items 181-192 of 1105

Set Descending Direction
  1. BZH02/Z0000/71 | BZH02Z000071 | Polysnap IEC Inlet
    BZH02/Z0000/71 | BZH02Z000071 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with single pole red neon marked switch
  2. BZH02/Z0000/74 | BZH02Z000074 | Polysnap IEC Inlet
    BZH02/Z0000/74 | BZH02Z000074 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with single pole green neon marked switch
  3. BZH02/Z0000/76 | BZH02Z000076 | Polysnap IEC Inlet
    BZH02/Z0000/76 | BZH02Z000076 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with double pole neon red marked switch
  4. BZH02/Z0000/77 | BZH02Z000077 | Polysnap IEC Inlet
    BZH02/Z0000/77 | BZH02Z000077 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with double pole neon green marked switch
  5. BZH02/Z0000/78 | BZH02Z000078 | Polysnap IEC Inlet
    BZH02/Z0000/78 | BZH02Z000078 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with double pole high inrush marked switch
  6. BZH02/Z0000/98 | BZH02Z000098 | Polysnap IEC Inlet
    BZH02/Z0000/98 | BZH02Z000098 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with single pole high inrush marked switch
  7. BZH02/Z0000/B1 | BZH02Z0000B1 | Polysnap IEC Inlet
    BZH02/Z0000/B1 | BZH02Z0000B1 | Polysnap IEC Inlet
    Polysnap IEC Single Fused Power Inlet with double pole high inrush green neon marked switch
  8. BZH09/Z0000/01 | BZH09Z000001 | Polysnap IEC Inlet / Outlet
    BZH09/Z0000/01 | BZH09Z000001 | Polysnap IEC Inlet / Outlet
    Polysnap IEC Fused C14 Inlet and Sheet F Non-Shuttered Power Outlet with single pole switch
  9. BZH09/Z0000/02 | BZH09Z000002 | Polysnap IEC Inlet / Outlet
    BZH09/Z0000/02 | BZH09Z000002 | Polysnap IEC Inlet / Outlet
    Polysnap IEC Fused C14 Inlet and Sheet F Non-Shuttered Power Outlet with single pole red neon switch
  10. BZH09/Z0000/03 | BZH09Z000003 | Polysnap IEC Inlet / Outlet
    BZH09/Z0000/03 | BZH09Z000003 | Polysnap IEC Inlet / Outlet
    Polysnap IEC Fused C14 Inlet and Sheet F Non-Shuttered Power Outlet with red neon indicator
  11. BZH09/Z0000/08 | BZH09Z000008 | Polysnap IEC Inlet / Outlet
    BZH09/Z0000/08 | BZH09Z000008 | Polysnap IEC Inlet / Outlet
    Polysnap IEC Fused C14 Inlet and Sheet F Non-Shuttered Power Outlet with single pole green neon switch
  12. BZH09/Z0000/46 | BZH09Z000046 | Polysnap IEC Inlet / Outlet
    BZH09/Z0000/46 | BZH09Z000046 | Polysnap IEC Inlet / Outlet
    Polysnap IEC Fused C14 Inlet and Sheet F Non-Shuttered Power Outlet with single pole high inrush switch
