FB-MUX/HS/DIO-NAM/PA | 2316270 | Multiplexer
Head station can be used with up to three 4-channel NAMUR digital input modules (RAD-NAM4-IFS) and two 4-channel digital output modules (RAD-DOR4-IFS) ***No longer in product range***
| Complete Electronics Part No. | 2702321 |
|---|---|
| Manufacturers Part No. | 2702321 |
| Ethernet Product Type: | Multiplexer |
Description
Multiplexer - FB-MUX/HS/DIO-NAM/PA
***No longer in product range***
- Allows the integration of standard Radioline I/O modules to a Profibus PA network
- Supply Voltage: 19.2...30.5 V DC
- Max current consumption: 50 mA (At 24 V DC, at 25°C)
- Protective Circuit: Transient voltage suppression; Suppressor diode
- This configuration can be used as a valve coupler solution to open and close, as well as monitor, the position of a valve
- Web-based management
- UL Listed
- Suitable for ATEX Zone 2
- No software needed thanks to a pre-configured head station
- Connection of all I/O field signals with standard PROFIBUS PA cable
- PROFIBUS Transmission Speed: 31.25 Kbps
- Width: 17.5 mm
- Height: 114.5 mm
- Depth: 99mm
- Colour: Grey
- DIN Rail Mounting
- Ingress protection: IP20
- Operating Temperature: -40°C ... 70°C
- Weight per Piece (excluding packing): 185.1 g
- Part Number 2316270
- Customs tariff number: 85176200
- Country of origin: US
