FL MC EF 1300 MM SC | 2902853 | FO Converter

FO converter with SC duplex fiber optic connection (1300 nm), for converting 10/100Base-T(X) to multi-mode fiberglass (50/125 µm)
More Information
Complete Electronics Part No 2902854
Manufacturers Part No. 2902854
Phoenix Ethernet Series FO Converters TX - FO
Total 10/100 (RJ45) Ports 1
Total Ethernet Ports 2
FX (Optical) Port Connector Type SC Duplex
FX (Optical) Cable Type Multi Mode (MM)
IP Rating IP20
Description

FO converter with SC FO connection (1300 nm)

  • For converting 10/100Base-T(X) to multi mode fiberglass (50/125 µm)
  • Auto negotiation
  • Auto MDI(X) function
  • Comprehensive link diagnostics
  • Store and forward media converter
  • Transmission speed: 10/100 Mbps (RJ45 shielded)
  • DIN-rail mountable
  • Supply Voltage: 18...30 V DC
  • Power Connection method: Plug-in screw terminal block (COMBICON), redundancy possible
  • Multi-mode fiberglass / GI-HCS
  • Fibre Types: 50/125 µm, 62.5/125 µm, Fiberglass
  • Transmission ranges up to 10 km
  • Fibre Connector: SC Duplex
  • Signal LED's: Activity, link status, 10/100 Mbps
  • Typical current consumption: 100 mA (at 24 V DC)
  • Reverse polarity protection
  • Width: 22.5mm
  • Height: 99mm
  • Depth: 114.5mm
  • Housing material: PA 6.6-FR
  • Colour: Green
  • Ingress protection: IP20
  • Operating Temperature: -40 °C ... 65 °C
  • Weight per Piece (excluding packing): 178.7 g
  • Part Number 2902853
  • Customs tariff number: 85176200
  • Country of origin: DE
