FL SWITCH 2105 | 2702665 | Ethernet Switch
Managed Ethernet switch, 8 x RJ45 10/100/1000 Ports, PROFINET Conformance-Class A, Auto negotiation and autocrossing
| Complete Electronics Part No. | 2702665 |
|---|---|
| Manufacturers Part No. | 2702665 |
| Phoenix Ethernet Series: | Managed NAT Switch 2000 |
| Managed / Unmanaged: | Managed |
| Total 10/100/1000 (RJ45) Ports | 8 |
| Total Ethernet Ports | 8 |
| IP Rating: | IP20 |
Description
Managed Ethernet switch
8 x RJ45 ports 10/100/1000 Mbps
- Auto negotiation and autocrossing (RJ45 Interface)
- Transmission Length: 100 m (per segment)
- Signal LED's: Data receive, link status
- PROFINET Conformance-Class A
- Supply Voltage: 24 V DC (Single)
- Supply Voltage Range: 18 V DC....32 V DC
- Connection Method: Screw Connection
- Typical Current Consumption: 275 mA (at US = 24 V DC and 25 °C ambient temperature)
- Power Supply Connection Method:via COMBICON, max. conductor cross section 1.5 mm²
- Connection Method: Push-in spring connection
- Degree of protection: IP20
- Operating Temperature: -0°C ... 60°C
- Width: 45 mm
- Height: 130 mm
- Depth: 115 mm
- Mounting Type: DIN Rail
- Housing: Polycarbonate fiber reinforced
- Weight per Piece (excluding packing): 240 g
- Part Number 2702665
- GTIN: 4055626283425
- Customs tariff number: 85176200
- Country of origin: DE
