FL SWITCH 2303-8SP1 | 1278397 | Ethernet Switch

Managed Switch 2000, 3 RJ45 ports 10/100/1000 Mbps, PROFINET Conformance-Class B, Extended temperature range, 8 x Single Pair Ethernet ports with PoDL

More Information
Complete Electronics Part No. 1278397
Manufacturers Part No. 1278397
Phoenix Ethernet Series: Managed Switch 2000
Managed / Unmanaged: Managed
Total 10/100/1000 (RJ45) Ports: 3
Total SPE Ports: 8
Total Ethernet Ports: 11
IP Rating: IP20
Description

FL SWITCH 2303-8SP1

Managed Ethernet Switch

Ethernet (RJ45)

Transmission speed: 10/100/1000 Mbps
RJ45 jack x 3
Transmission length: 100 m (per segment)
Signal LED's:  Data receive, link status
Auto negotiation and Auto Crossing
Store-and-forward switch, complies with IEEE 802.3


Ethernet (SPE)

8 ports Single Pair Ethernet
10BASE T1L
PoDL Power Class 11
10 Mbps (full duplex)
Transmission length 1000 m (per segment)
Signal LEDs: Data receive, link status

Ethernet (Optical)

N/A

Functions

Managed switch
RSTP
MRP (client and manager)
VLANs
Quality of Service (8 priority classes)
DHCP client, DHCP server (pool-based and port-based), DHCP option 82
Suitable for PROFINET and EtherNet/IP™ networks
PROFINET Conformance Class B
Store and Forward switching mode
Supply voltage: 24 V DC (Simultaneous PoDL supply according to IEEE 802.3cg)
Supply voltage range:20 V DC ... 32 V DC
Power supply connection: via COMBICON, max. conductor cross section 1.5 mm²
Typical current consumption: 65 W (100% data traffic on all connected ports)
Degree of protection: IP20
Operating Temperature: -40°C ... 70°C
Approvals: cULus Listed, Approval ID: E238705


Dimensions

Width: 45mm
Height: 130mm
Depth: 119mm
Housing Material: Polycarbonate fiber reinforced
Mounting Type: DIN Rail


Commercial data

Weight per Piece (excluding packing): 347 g
Part Number: 1278397
GTIN: 4063151475925
Customs Tariff Number: 85176200
Minimum Order Quantity: 1pc.
Country Of Origin: DE
