FL SWITCH SFNB 5TX-50PK | 2891014 | Ethernet Switch
Rack-mount Unmanaged Ethernet switch, 24 x RJ45 10/100 Ports, auto crossing function, installs in 19-in. (482 mm) rack ***No longer in product range***
| Complete Electronics Part No. | 2891014 |
|---|---|
| Manufacturers Part No. | 2891014 |
| Phoenix Ethernet Series: | Unmanaged Switch SFNB |
| Managed / Unmanaged: | Unmanaged |
| Total 10/100/1000 (RJ45) Ports: | 5 |
| Total Ethernet Ports: | 5 |
| IP Rating: | IP20 |
Description
DIN Rail Unmanaged Ethernet switch
5 x RJ45 ports 10/100 Mbps
***No longer in product range***
Auto negotiation and autocrossing
Signal LED's: Activity, Link Status
Transmission Length: 100 m
Power Supply Connection: Via COMBICON, max. conductor cross section 2.5 mm²
Connection Method: Screw Connection
Supply Voltage: 24 V DC
Supply Voltage Range: 12 V DC....24 V DC
Typical Current Consumption: 185 mA (@24 V DC)
Degree of protection: IP20
Operating Temperature: -10 °C ... 60 °C
Width: 28mm
Height: 110mm
Depth: 70mm
Mounting Type: DIN Rail
Weight per Piece (excluding packing): 205 g
Part Number 2891014
GTIN: 4046356675369
Customs tariff number: 85176200
Country of origin: TW
