KRESL0503 | KRESL 05/03 | Terminal Block
3 Pole Screw terminal block, clamp with wire protector (1000 V) 90° angular
| Complete Electronics Part No. | KRESL0503 |
|---|---|
| Manufacturers Part No. | KRESL 05/03 |
| Terminal Block Type: | Screw |
| Number Of Positions: | 3 |
Description
KRESL 05/03
- 3 Pole Screw terminal block
- Clamp with wire protector
- 90° angular
- Consecutive placement without loss of pitch
- Temperature range -25 °C/+125 °C
- Insulating body PA, V2 according to UL 94
- Screw M2.6
- Rated current 15 A at Tamb 100 °C (VDE), 10/20 A (UL)2
- Rated voltage 1000 V AC (VDE), 300 V (UL)2
- Insulation resistance > 1 GΩ
