KRESL0704 | KRESL 07/04 | Terminal Block
4 Pole Screw terminal block, clamp with wire protector (1000 V) 90° angular
| Complete Electronics Part No. | KRESL0704 |
|---|---|
| Manufacturers Part No. | KRESL 07/04 |
| Terminal Block Type: | Screw |
| Number Of Positions: | 4 |
Description
KRESL 07/04
- 4 Pole Screw terminal block,
- Clamp with wire protector,
- 90° angular,
- Consecutive placement without loss of pitch
- Temperature range -25 °C/+125 °C
- Insulating body PA, V2 according to UL 94
- Screw M2.6
- Rated current 15 A at Tamb 100 °C (VDE), 10/20 A (UL)2
- Rated voltage 1000 V AC (VDE), 300 V (UL)2
- Insulation resistance > 1 GΩ
