KRESL09 | KRESL 09 | Terminal Block
9 Pole Screw terminal block, clamp with wire protector, right angle
| Complete Electronics Part No. | KRESL09 |
|---|---|
| Manufacturers Part No. | KRESL 09 |
| Terminal Block Type: | Screw |
| Number Of Positions: | 9 |
Description
KRESL 09
- 2 Pole Screw terminal block
- Clamp with wire protector
- Right angle version
- Consecutive placement without loss of pitch
- Temperature range -25 °C/+100 °C
- Body PA V2 according to UL 94
- Clamp CuZn, pre-nickeled and tinned Wire protector CuSn, pre-nickeled and tinned
- Screw steel, zincked and chromated
- Screw M2.6 max. section 2.5 mm2
- Rated current 15 A
- Rated voltage2 250 V AC Overvoltage category2 III
