KRESW0302 | KRESW 03/02 | Terminal block
2 Pole Screw terminal block, clamp with wire protector (1000 V), 45° angular.
| Complete Electronics Part No. | KRESW0302 |
|---|---|
| Manufacturers Part No. | KRESW 03/02 |
| Terminal Block Type: | Screw |
| Number Of Positions: | 2 |
Description
KRESW 03/02
- 2 Pole Screw terminal block,
- Clamp with wire protector,
- 45° angular,
- Consecutive placement without loss of pitch
- Temperature range -25 °C/+125 °C1
- Wire protector CuSn, pre-nickel and tin-plated
- Screw steel, zinck-plated and chromated
- Screw M2.6
- Solid or stranded wire, with or without wire end sleeve Section 0.2–2.5 mm2 (AWG 12–22/24)
- Electrical data (at Tamb 20 °C)
- Rated current 15 A at Tamb 100 °C (VDE), 10/20 A (UL)2
- Rated voltage 1000 V AC (VDE), 300 V (UL)2
- Insulation resistance > 1 GΩ
