677006K00 | 6770 06 K00 | Terminal Block
6 Pole Pluggable terminal block
| Complete Electronics Part No. | 677006K00 |
|---|---|
| Manufacturers Part No. | 6770 06 K00 |
| Terminal Block Type: | Plugable Screw |
| Number Of Positions: | 6 |
Description
6770 06 K00
- 6 Pole Pluggable terminal block
- Insulation displacement technology (IDT)
- With locking and test hole
- Cable departure 90°
- Contact resistance ≤ 5 mΩ
- Rated current 6 A/0.75 mm2 at Tamb 70 °C
- Rated voltage 250 V AC
- Overvoltage category III (2.5 kV)
- Temperature range -25 °C/+100 °C
