PXM7011/03S/ST/1315/SN | PXM701103SST1315SN | Bulgin 7000 Series
7000 Series Buccaneer Metal 3 Pole Female Flex In-Line Cable Connector
| Complete Electronics Part No. | PXM701103SST1315SN |
|---|---|
| Manufacturers Part No. | PXM7011/03S/ST/1315/SN |
| Type: | Cable Socket |
| Mounting: | Cable |
| Number of poles | 3 |
| Cable Gland Size: | 13-15 mm |
| Termination: | Crimp |
| Male/Female: | Female |
| Housing Construction: | Metal |
| Cable Entry: | Straight |
| Rated Voltage: | 600V |
| Rated Current: | 25A |
| IP Rating: | IP66 / 68 / 69K |
Description
PXM7011/03S/ST/1315/SN
3 Pole Female Front Panel Mount Connector
- Voltage: 600Vac/dc
- Current: 25 Amps
- Gender: Female
- Application: Cable Mount
- Contacts: Sockets
- Termination: Screw
- With Braid Termination Accessory
- Temperature range -40 °C/+120 °C
- Mates With Flex Cable Connector PXM7010 ;
