PXP7010/10P/CR/0911/SN | PXP701010PCR0911SN | Bulgin 7000 Series

7000 Series Buccaneer Plastic 10 Pole Male Flex Cable Connector
More Information
Complete Electronics Part No. PXP701010PCR0911SN
Manufacturers Part No. PXP7010/10P/CR/0911/SN
Type: Cable Plug
Mounting: Cable
Number of poles 10
Termination: Crimp
Male/Female: Male
Housing Construction: Plastic
Rated Voltage: 600V
Rated Current: 10A
IP Rating: IP66 / 68 / 69K
Description

PXP701010PCR0911SN

7000 Series Buccaneer Plastic 10 Pole Male Flex Cable Connector

  • Mates with Flex In-Line or Panel Mount Versions
  • Voltage: 600Vac/dc
  • Current: 10Amps
  • Gender: Male
  • Application: Cable Mount
  • Contacts: Pins
  • Termination: Crimp, excluded, order separately
  • Includes Cable Braid Termination
  • Temperature: –40° to +120°C
  • Gland Size:9-11mm
  • IP Rating: Water and Dust Proof to IP66 / IP68 / IP69
  • Approvals: UL, CSA, VDE & CCC
