RAD-900-ANT-OMNI-2-N | 2904802 | Antenna
Omnidirectional antenna 868 MHz / 900 MHz, gain: 2 dBi, polarization: linear, opening angle: h/v 360°/50°, IP66, connection: N (female)
| Complete Electronics Part No. | 2904802 |
|---|---|
| Manufacturers Part No. | 2904802 |
| Ethernet Product Type: | Antenna |
Description
Antenna - RAD-900-ANT-OMNI-2-N
- Omnidirectional antenna
- Frequency 868 MHz / 900 MHz
- Impedance: 50 Ω
- Gain 2 dBi
- Polarization: Linear
- Opening angle: h/v 360°/50°
- Connection method: N (female)
- Ingress Protection: IP66
- Antenna housing: Xenoy 5720U-7014
- For control panel mounting
- Optional Wall mounting available
- Diameter:: 36 mm
- Height: 84 mm
- Operating Temperature: -40°C ... 70°C
- Weight per Piece (excluding packing): 171.5 g
- Part Number 2904802
- Customs tariff number: 85177100
- Country of origin: US
