RAD-ISM-900-ANT-YAGI-3-N | 2867801 | Antenna
Directional antenna, 868 MHz / 900 MHz, gain: 5 dBi, polarization: linear, opening angle: h/v 168°/78°, Ingress protection: IP65, connection: N female
| Complete Electronics Part No. | 2867801 |
|---|---|
| Manufacturers Part No. | 2867801 |
| Ethernet Product Type: | Antenna |
Description
Antenna - RAD-ISM-900-ANT-YAGI-3-N
- Directional antenna
- For stationary or linear mobile applications
- For point-to-point connections
- For large distances
- Frequency 868 MHz / 900 MHz
- Impedance: 50 Ω
- Gain 5 dBi
- Polarization: linear
- Opening angle: h/v 168°/78°
- Connection method: N (female) with cable (0.6 m)
- Ingress Protection: IP65
- Antenna housing: Aluminium
- Bracket: V2A
- U-shaped screw: V2A
- Width: 6 cm
- Height: 17cm
- Cable Length: 0.60m
- Operating Temperature: -40°C ... 80°C
- Weight per Piece (excluding packing): 1205 g
- Part Number 2867801
- Customs tariff number: 85177100
- Country of origin: US
