SPIDER-PL-20-01T1M29999TZ9HHHH | 942141022 | Industrial Ethernet

Unmanaged, Industrial ETHERNET Rail Switch, 10/100 Mbit/s Ethernet, 1x 10/100BASE-TX, TP cable, 1 x 100BASE-FX, MM cable, SC sockets

More Information
Complete Electronics Part No. 942141022
Manufacturers Part No. 942141022
Ethernet Product Type: Unmanaged Switch
Total 10/100 (RJ45) Ports: 1
Total 100 Base Ports: 1
Total Ethernet Ports: 2
TX (Copper) Port Connector Type: RJ45
FX (Optical) Connector Type: SC
FX (Optical) Cable Type: Multi Mode (MM)
Operating Voltage: DC 9.6V - 32V
Mounting: DIN Rail
IP Rating: IP40
Description

SPIDER-PL-20-01T1M29999TZ9HHHH

Unmanaged, Industrial ETHERNET Rail Switch

  • 1x 10/100BASE-TX, RJ45 sockets
  • 1 x 100BASE-FX, MM cable, SC sockets
  • Auto-crossing
  • Auto-negotiation
  • Auto-polarity
  • Operating voltage: 12/24 V DC (9.6 - 32 V DC)
  • Mounting: DIN Rail
  • Protection class: IP40
  • Part Number: 942141022

***This product is being discontinued***
     Last Order Date September 30th 2023

Suggested Alternative: 942335030, SPR20-7TX/2FM-EEC
6 additional RJ45 ports & 1 additional fiber multimode port SC
  • Accessories: Rail Power Supply RPS 30/80 EEC/120 EEC (CC)
  • Wall mounting plate for DIN rail mounting (width 40/70 mm)
