2278445 | MKDSO 1,5/ 3-L-3,5 KMGY | PCB terminal block
PCB terminal block, For ME/ME MAX electronics housing, Nominal current: 8A, Nominal voltage: 160V, Pitch: 3.5 mm, Number of positions: 4
| Complete Electronics Part No. | 2278445 |
|---|---|
| Manufacturers Part No. | 2278445 |
| Pitch | 3.5mm |
| Terminal Block Type: | PCB |
| Number Of Positions: | 3 |
Description
MKDSO 1,5/ 3-L-3,5 KMGY
PCB terminal block
- For ME/ME MAX electronics housing
- Nominal current: 8A
- Nominal voltage: 160V
- Pitch: 3.5 mm
- Number of positions: 3
- Screw connection with tension sleeve,
- Mounting: Wave soldering
- Colour: Light Grey
- Material: Polyamide
- With lateral pin exit
- Weight per Piece (excluding packing) 3.320 g
- Country of origin: China
