44423075 | Lapp Circular Connector | Epic® Power M12
Epic® Power M17 A1 Female, For Servo Motors and Power Supply, Number of Contacts: 3+PE (2mm), Termination: Crimp, Rated Voltage: 630V, Rated Current: 20A
| Complete Electronics Part No. | 44423075 |
|---|---|
| Manufacturers Part No. | 44423075 |
| Type: | Connector Body |
| Lapp Circular Range: | Power M17 A1 |
| Number of poles | 3+PE |
| Male/Female: | Female |
| Termination: | Crimp |
| Mounting: | Panel Mount |
Description
Part Number 44423075
Epic® Power M17 A1 Female
- For Servo Motors and Power Supply
- Panel Mounting
- Fastening Type: Ø 2.7mm x4
- Number of Contacts: 3+PE (2mm)
- Termination: Crimp
- Rated Voltage: 630V
- Rated Current: 20A
- Protection Rating: IP67
- ContactsL: Gold Plated Brass
- Temperature Range: -40°C to +125°C
***Crimps to be purchased separately - see Accessories Section***
