PX0745/P/07/WH1 | PX0745P07WH1 | Connector
Standard Series Buccaneer 7 Pole Male Flex Cable Connector with 7-9mm cable gland, white insert & cable gland
| Complete Electronics Part No. | PX0745P07WH1 |
|---|---|
| Manufacturers Part No. | PX0745/P/07/WH1 |
| Type: | Cable Plug |
| Mounting: | Cable |
| Number of poles | 7 |
| Termination: | Screw |
| Male/Female: | Male |
| Rated Voltage: | 277V |
| Rated Current: | 5A |
| IP Rating: | IP68 |
Description
PX0745P07WH1
Standard Series Buccaneer 7 Pole Male Flex Cable Connector
- With 7-9mm cable gland, white insert & cable gland
- Mates with In-Line Flex or Panel Mount Versions
- Voltage: 277Vac/dc
- Current: 5Amps
- Application: Cable Mount
- Contacts: Pins
- Termination: Screw
- Temperature: -20 °C/+70 °C
- IP Rating: Water and Dust to IP68
- Approvals: UL, CSA & VDE
