PX0745/P/07/WH1 | PX0745P07WH1 | Connector

Standard Series Buccaneer 7 Pole Male Flex Cable Connector with 7-9mm cable gland, white insert & cable gland
More Information
Complete Electronics Part No. PX0745P07WH1
Manufacturers Part No. PX0745/P/07/WH1
Type: Cable Plug
Mounting: Cable
Number of poles 7
Termination: Screw
Male/Female: Male
Rated Voltage: 277V
Rated Current: 5A
IP Rating: IP68
Description

PX0745P07WH1

Standard Series Buccaneer 7 Pole Male Flex Cable Connector

  • With 7-9mm cable gland, white insert & cable gland
  • Mates with In-Line Flex or Panel Mount Versions
  • Voltage: 277Vac/dc
  • Current: 5Amps
  • Application: Cable Mount
  • Contacts: Pins
  • Termination: Screw
  • Temperature: -20 °C/+70 °C
  • IP Rating: Water and Dust to IP68
  • Approvals: UL, CSA & VDE
