PXEB5220MM4550 | Flange Mount Bulkhead Connector | 5000 Series

Non-terminated Connector for a 2 Channel Cable, Mates with Plug Connectors (hermaphroditic), Compatible with OM1 &  OM3 cable

More Information
Complete Electronics Part No PXEB5220MM4550
Manufacturers Part No. PXEB5220MM4550
Type Flange Mount
Mounting Bulkhead Mounting
Number of poles 2 Channels
Cable Diameter 4.5 - 5mm
Description

PXEB5220MM4550

2 Channel Flange Mount Bulkhead Connector

With Cable Retention
Non-terminated Connector for a 2-Channel Cable
Designed to MIL-DTL-83526D
Secure, proven locking system
Cable Acceptance: 4.5mm to 5.0mm
Compatible with multimode OM1 & OM3 cables
Dust Cap, Lanyard, &  Ferrules (termini) included
Mates with Plug Connectors (hermaphroditic)
Operating Temperature Range:-50⁰C to +80⁰C
Maximum Panel Thickness 4.7mm
UL94-V0 rated
UV stable
Halogen Free
Suitable for long term outdoor use
Ingress protection: IP68
Part Number: PXEB5220MM4550
