SCX 2POE 2T | 1108544 | Industrial Ethernet Switch

Smart Camera Box to connect PoE end devices, two PoE ports, two uplink ports (RJ45), integrated Managed Switch and surge protection
More Information
Complete Electronics Part No. 1108544
Manufacturers Part No. 1108544
Description

Ethernet Switch SCX 2POE 2T

  • The Smart Camera Box is used to connect PoE end devices such as IP cameras to a video server
  • Psh in spring connection
  • Supply voltage range: 100 V AC ... 240 V AC -15 % ... +10 % (Single-phase)
  • Ethernet TX Speed: 10/100/1000
  • Connection: 2 x RJ45 Jack
  • Max output power: 165 W (>55°C derating)
  • Fast Ethernet TX speed: 10/100/1000 Mbps
  • Connection Method: 2 x RJ45 ports
  • Configuration interface: 1 x RJ45
  • Push in spring connection
  • Width 284mm
  • Height: 364mm
  • Depth: 121mm
  • Colour: Light Grey
  • Housing Material: Polycarbonate PC (Housing)
  • Impact Strength: IK10 (in accordance with IEC 62262: Impact energy of 20 J, corresponds to 5 kg from a height of 40 cm)
  • Wall / Mast mounting
  • Ingress Protection: IP65
  • UV-resistant in accordance with UL746C
  • Weight Per piece (not including packing): 4300 g
  • Part Number: 1108544
  • Customs tariff number: 85176200
  • Country of origin: DE
